Introduction to Nmap

• Overview: Nmap (Network Mapper) is an open-source tool for network analysis and security auditing, written in C, C++, Python, and Lua.
• Capabilities:
  • Scans networks to identify available hosts using raw packets.
  • Detects services, applications, and their versions.
  • Identifies operating systems and versions.
  • Checks for packet filters, firewalls, or intrusion detection systems (IDS).
• Use Cases:
  • Network security auditing.
  • Simulating penetration tests.
  • Verifying firewall and IDS configurations.
  • Mapping networks and analyzing responses.
  • Identifying open ports and assessing vulnerabilities.

Nmap Architecture

• Scanning Techniques:

  • Host discovery
  • Port scanning
  • Service enumeration and detection
  • OS detection
  • Scriptable interaction via Nmap Scripting Engine (NSE)

• Syntax:

  nmap <scan types> <options> <target>

Scan Techniques

• TCP Scans:
  • SYN Scan (-sS): Default, fast, sends SYN packet, does not complete TCP handshake.
    • Open port: Returns SYN-ACK.
    • Closed port: Returns RST.
    • Filtered: No response, possibly dropped by firewall.
  • Connect Scan (-sT): Completes TCP three-way handshake, accurate but less stealthy, logs connections.
  • Other TCP scans: ACK (-sA), Window (-sW), Maimon (-sM), Null (-sN), FIN (-sF), Xmas (-sX).
• UDP Scan (-sU): Slower due to stateless nature, no handshake, longer timeouts.
• Other Scans:
  • SCTP INIT/COOKIE-ECHO (-sY/-sZ)
  • IP protocol scan (-sO)
  • Idle scan (-sI)
  • FTP bounce scan (-b)
• Custom Flags: --scanflags for customized TCP scan flags.

Example: TCP SYN Scan

sudo nmap -sS localhost

• Output:
  • Open ports: 22/tcp (ssh), 80/tcp (http), 5432/tcp (postgresql), 5901/tcp (vnc-1).
  • Closed ports: 996 not shown.

Host Discovery

• Purpose: Identify active hosts before port scanning.
• Methods:
  • ICMP echo requests (-PE): Default ping scan.
  • ARP ping: Used in local networks, can be disabled with --disable-arp-ping.
• Options:
  • -sn: Disables port scanning, focuses on host discovery.
  • -oA <filename>: Saves results in all formats (normal, greppable, XML).
  • -iL <file>: Scans IPs from a provided list.
  • --packet-trace: Shows sent/received packets.
  • --reason: Explains why a host is marked alive.

Example: Network Range Scan

sudo nmap 10.0.0.0/24 -sn -oA tnet

• Output: Lists active IPs (e.g., 10.0.0.4, 10.0.0.10, etc.).
• Note: Firewalls may block ICMP, requiring alternative techniques.

Example: Single IP Scan

sudo nmap 10.0.0.18 -sn -oA host -PE --packet-trace

• Output: Confirms host is up via ICMP or ARP reply.

Port Scanning

• Port States:
  • Open: Connection established (TCP, UDP, SCTP).
  • Closed: RST packet received (TCP).
  • Filtered: No response, likely firewall-protected.
  • Unfiltered: Accessible but state unclear (TCP-ACK scan).
  • Open|Filtered: No response, possibly open or filtered (UDP).
  • Closed|Filtered: Unclear if closed or filtered (Idle scan).
• Default Behavior:
  • Scans top 1000 TCP ports with SYN scan (-sS) if run as root.
  • Uses Connect scan (-sT) otherwise.
• Port Selection:
  • Specific ports: -p 22,80,443
  • Range: -p 1-1000
  • Top ports: --top-ports 10
  • All ports: -p-
  • Fast scan: -F (top 100 ports)

Example: Top 10 TCP Ports

sudo nmap 10.0.0.28 --top-ports 10

• Output:
  • Open: 22/tcp (ssh), 25/tcp (smtp), 80/tcp (http), 110/tcp (pop3).
  • Closed: 21/tcp (ftp), 23/tcp (telnet), 443/tcp (https), 3389/tcp (ms-wbt-server).
  • Filtered: 139/tcp (netbios-ssn), 445/tcp (microsoft-ds).

Example: Filtered Port

sudo nmap 10.0.0.28 -p 139 --packet-trace -Pn -n --disable-arp-ping

• Output: No response, port 139/tcp marked as filtered, likely due to firewall dropping packets.

UDP Scanning

• Challenges:
  • Stateless protocol, no handshake.
  • Slower due to timeouts.
  • Empty datagrams may not elicit responses.
• Port States:
  • Open: Application responds.
  • Closed: ICMP port unreachable (type 3, code 3).
  • Open|Filtered: No response.
• Example:

  sudo nmap 10.0.0.28 -sU -p 137 --packet-trace --reason

  • Output: 137/udp open (netbios-ns) with UDP response.

Service Version Detection

• Option: -sV
• Purpose: Identifies service names, versions, and additional details.
• Example:

  sudo nmap 10.0.0.28 -p 445 -sV --packet-trace --reason

  • Output: 445/tcp open, running Samba smbd 3.X - 4.X (workgroup: WORKGROUP), host: Ubuntu.

Saving Results

• Formats:
  • Normal (.nmap): Human-readable.
  • Greppable (.gnmap): Script-friendly.
  • XML (.xml): Structured, convertible to HTML.
• Option: -oA <filename> saves in all formats.
• Example:

  sudo nmap 10.0.0.28 -p- -oA target

  • Output Files: target.nmap, target.gnmap, target.xml.
• HTML Conversion:

  xsltproc target.xml -o target.html

  • Creates a readable HTML report.

Key Considerations

• Stealth:
  • SYN scan is stealthier than Connect scan due to incomplete handshake.
  • Modern IDS/IPS can detect both.
• Firewalls:
  • May drop or reject packets, affecting results.
  • Use --packet-trace and --reason to diagnose.
• Performance:
  • UDP scans are slower than TCP.
  • Use -F or --top-ports for faster scans.
• Documentation:
  • Always save results for comparison and reporting.
  • XML format is ideal for generating professional reports.

Resources

• Port scanning techniques: Nmap Port Scanning Techniques
• Host discovery strategies: Nmap Host Discovery Strategies

Service Enumeration

Overview: Identifying the exact application and version running on open ports is critical for finding vulnerabilities and exploits.

• Purpose:
  • Determine service versions to search for known vulnerabilities.
  • Analyze source code for specific versions.
  • Find precise exploits matching the service and OS.

Service Version Detection

• Option: -sV

• Strategy:

  • Perform a quick port scan (e.g., -F or --top-ports) to identify open ports with minimal traffic.
  • Run a full port scan (-p-) in the background for comprehensive results.
  • Use -sV on specific ports to detect service versions.

• Monitoring:

  • Press Space Bar during scan to check status.
  • Use --stats-every 5s for periodic progress updates.
  • Increase verbosity (-v or -vv) to display open ports as they are found.

• Example:

  sudo nmap 10.0.0.28 -p- -sV -v

  • Output:
    • Open ports: 22/tcp (OpenSSH 7.6p1 Ubuntu), 25/tcp (Postfix smtpd), 80/tcp (Apache 2.4.29), 110/tcp (Dovecot pop3d), 143/tcp (Dovecot imapd), 993/tcp (Dovecot imapd SSL), 995/tcp (Dovecot pop3d SSL).
    • Filtered: 139/tcp (netbios-ssn), 445/tcp (microsoft-ds).
    • Service Info: Host: inlane, OS: Linux, CPE: cpe:/o:linux:linux_kernel.

Banner Grabbing

• Purpose: Extract service banners to gather additional details (e.g., OS distribution).

• Limitations:

  • Nmap may miss banner details if it cannot interpret them.
  • Some services may not send banners or have manipulated banners.

• Manual Verification:

  • Use tools like nc (netcat) to connect to services and grab banners.
  • Monitor traffic with tcpdump to capture full responses.

• Example:

  nc -nv 10.0.0.28 25

  • Output: 220 inlane ESMTP Postfix (Ubuntu) (reveals Ubuntu distribution).

  sudo tcpdump -i eth0 host 10.10.14.2 and 10.0.0.28

  • Output: Captures TCP handshake and PSH-ACK packet with banner data.

Nmap Scripting Engine (NSE)

Overview: NSE allows Lua scripts to interact with services, enhancing Nmap’s functionality.

• Script Categories:
  • auth: Tests authentication credentials.
  • broadcast: Discovers hosts via broadcasting.
  • brute: Attempts credential brute-forcing.
  • default: Runs with -sC option.
  • discovery: Evaluates accessible services.
  • dos: Checks for DoS vulnerabilities (use cautiously).
  • exploit: Tests for known vulnerabilities.
  • external: Uses external services for processing.
  • fuzzer: Identifies vulnerabilities via unexpected packets.
  • intrusive: Aggressive scripts that may disrupt services.
  • malware: Detects malware infections.
  • safe: Non-disruptive scripts.
  • version: Extends version detection.
  • vuln: Checks for known vulnerabilities.

Running Scripts

• Options:

  • --script <script-name>: Run specific scripts.
  • --script <category>: Run all scripts in a category.
  • -sC: Run default scripts.
  • -A: Aggressive scan (includes -sV, -O, --traceroute, -sC).

• Example: Specific Scripts

  sudo nmap 10.0.0.28 -p 25 --script banner,smtp-commands

  • Output:
    • Banner: 220 inlane ESMTP Postfix (Ubuntu) (confirms Ubuntu).
    • SMTP commands: PIPELINING, SIZE, VRFY, ETRN, STARTTLS, etc.
    • Useful for identifying valid users or server capabilities.

• Example: Aggressive Scan

  sudo nmap 10.0.0.28 -p 80 -A

  • Output:
    • Service: Apache 2.4.29 (Ubuntu), WordPress 5.3.4.
    • OS guesses: Linux 2.6.32–4.9 (96% confidence).
    • Traceroute: 1 hop.

• Example: Vulnerability Scan

  sudo nmap 10.0.0.28 -p 80 -sV --script vuln

  • Output:
    • WordPress 5.3.4 detected, admin folder (/wp-login.php), user: admin.
    • Apache 2.4.29 vulnerabilities: CVE-2019-0211 (7.2), CVE-2018-1312 (6.8), CVE-2017-15715 (6.8).
    • No stored XSS found.

• Resource: NSE documentation at Nmap NSE Documentation.

Performance Optimization

Overview: Optimize Nmap scans for speed, especially on large networks or low-bandwidth environments.

• Key Options:
  • Timeouts:
    • --initial-rtt-timeout <time>: Initial timeout (default: 100ms).
    • --max-rtt-timeout <time>: Maximum timeout.
  • Retries:
    • --max-retries <number>: Number of packet retries (default: 10).
  • Rates:
    • --min-rate <number>: Minimum packets per second.
  • Timing Templates:
    • -T0 (paranoid) to -T5 (insane), with -T3 (normal) as default.

Examples

• Optimized RTT:

  sudo nmap 10.0.0.0/24 -F --initial-rtt-timeout 50ms --max-rtt-timeout 100ms

  • Result: Scan time reduced from 39.44s to 12.29s, but missed 2 hosts due to short timeout.

• Reduced Retries:

  sudo nmap 10.0.0.0/24 -F --max-retries 0

  • Result: Found 21 open ports vs. 23 with default retries, faster but less reliable.

• Packet Rate:

  sudo nmap 10.0.0.0/24 -F --min-rate 300 -oN tnet.minrate300

  • Result: Scan time reduced from 29.83s to 8.67s, same 23 open ports.

• Timing Template:

  sudo nmap 10.0.0.0/24 -F -T5 -oN tnet.T5

  • Result: Scan time reduced from 32.44s to 18.87s, same 23 open ports.

Considerations:

• Aggressive settings (-T5, low retries) may trigger security systems.
• Balance speed and accuracy based on network conditions.
• White-box tests allow higher rates if whitelisted.

Firewall and IDS/IPS Evasion

Overview: Nmap provides techniques to bypass firewalls and avoid detection by IDS/IPS.

• Firewalls:

  • Monitor and filter traffic based on rules.
  • Drop (no response) or reject (RST or ICMP error) packets.
  • Common ICMP errors: Net/Host/Port Unreachable, Net/Host/Proto Prohibited.

• IDS/IPS:

  • IDS: Passively monitors for attack patterns, alerts administrators.
  • IPS: Actively blocks detected threats.
  • Detection based on signatures or anomalies (e.g., aggressive scans).

Evasion Techniques

• TCP ACK Scan (-sA):

  • Sends ACK-only packets, harder to filter as firewalls may assume an existing connection.
  • Open/closed ports return RST; filtered ports return no response.

  sudo nmap 10.0.0.28 -p 21,22,25 -sA -Pn -n --disable-arp-ping --packet-trace

  • Output: 22/tcp unfiltered (ssh), 21/tcp and 25/tcp filtered.

• Decoys (-D):

  • Spoofs packets with random or specified IP addresses to mask the source.
  • Requires decoy IPs to be alive to avoid SYN-flood protections.

  sudo nmap 10.0.0.28 -p 80 -sS -Pn -n --disable-arp-ping --packet-trace -D RND:5

  • Output: Port 80/tcp open, scan appears to come from multiple IPs.

• Source IP Spoofing (-S):

  • Specify a trusted or internal IP to bypass subnet restrictions.

  sudo nmap 10.0.0.28 -n -Pn -p 445 -O -S 10.0.0.200 -e tun0

  • Output: 445/tcp open (microsoft-ds), OS guesses: Linux 2.6.32–4.9.

• Source Port Manipulation (—source-port):

  • Use trusted ports (e.g., 53 for DNS) to bypass firewall rules.

  sudo nmap 10.0.0.28 -p 50000 -sS -Pn -n --disable-arp-ping --source-port 53

  • Output: 50000/tcp open (ibm-db2), bypassed firewall.

• DNS Proxying (—dns-servers):

  • Use internal DNS servers to interact with DMZ or internal hosts.
  • DNS queries (UDP/TCP 53) are often trusted.

Detecting IDS/IPS

• Challenges:
  • Passive monitoring makes detection difficult.
  • IPS may block IPs without warning.
• Techniques:
  • Use multiple VPS IPs; if one is blocked, an IPS is likely present.
  • Perform aggressive scans (e.g., single-port hammering) to trigger administrator actions.
• Mitigation:
  • Use quieter scans (e.g., -T2, decoys).
  • Rotate VPS IPs to avoid blocks.

Considerations:

• Spoofed packets may be filtered by ISPs or routers.
• Test firewall rules incrementally to avoid detection.
• Use --packet-trace and --reason to analyze firewall behavior.

Key Considerations

• Stealth:
  • Use -sS, -sA, or decoys for stealthier scans.
  • Avoid -A or -T5 in black-box tests to reduce detection risk.
• Accuracy:
  • Manual banner grabbing (nc, tcpdump) complements Nmap’s -sV.
  • NSE scripts (vuln, exploit) enhance vulnerability detection.
• Performance:
  • Optimize timeouts, retries, and rates for large networks.
  • Use -F or --top-ports for quick reconnaissance.
• Evasion:
  • Combine decoys, source IP/port manipulation, and ACK scans to bypass protections.
  • Monitor scan traffic to detect IPS blocks.

Resources

• NSE scripts: Nmap NSE Documentation
• Firewall evasion: Nmap Firewall Evasion Techniques
